Throat Dia.D Specification&Dimension
|
d₀=14mm
154mm²
|
Flange Rating(Lb)
|
38°C Max. Back Press(Mpa)
|
Dimension(mm)
|
|
|
Inlet
|
Outlet
|
Normal Type
|
Bellows Type
|
L
|
L1
|
X
|
(VA500)H≈
|
|
1D2
|
150
|
150
|
1.96
|
1.58
|
114
|
105
|
30
|
440
|
|
1D2
|
300
|
150
|
1.96
|
1.58
|
114
|
105
|
30
|
440
|
|
1D2
|
300
|
150
|
1.96
|
1.58
|
114
|
105
|
30
|
440
|
|
1D2
|
600
|
150
|
1.96
|
1.58
|
114
|
105
|
30
|
440
|
Throat Dia.E Specification&Dimension
|
d₀=14mm
154mm²
|
Flange Rating(Lb)
|
38°C Max. Back Press(Mpa)
|
Dimension(mm)
|
|
|
Inlet
|
Outlet
|
Normal Type
|
Bellows Type
|
L
|
L1
|
X
|
(VA500)H≈
|
|
1E2
|
150
|
150
|
1.96
|
1.58
|
114
|
105
|
30
|
440
|
|
1E2
|
300
|
150
|
1.96
|
1.58
|
114
|
105
|
30
|
440
|
|
1E2
|
300
|
150
|
1.96
|
1.58
|
114
|
105
|
30
|
440
|
|
1E2
|
600
|
150
|
1.96
|
1.58
|
114
|
105
|
30
|
440
|
Throat Dia.F Specification&Dimension
|
d₀=18mm
254mm²
|
Flange Rating(Lb)
|
38°C Max. Back Press(Mpa)
|
Dimension(mm)
|
|
|
Inlet
|
Outlet
|
Normal Type
|
Bellows Type
|
L
|
L1
|
X
|
(VA500)H≈
|
|
11/2F2
|
150
|
150
|
1.96
|
1.58
|
121
|
124
|
32
|
536
|
|
11/2F2
|
300
|
150
|
1.96
|
1.58
|
121
|
124
|
32
|
536
|
|
11/2F2
|
300
|
150
|
1.96
|
1.58
|
152
|
124
|
35
|
536
|
|
11/2F2
|
600
|
150
|
1.96
|
1.58
|
152
|
124
|
35
|
536
|
Throat Dia.G Specification&Dimension
|
d₀=22.5mm
398mm²
|
Flange Rating(Lb)
|
38°C Max. Back Press(Mpa)
|
Dimension(mm)
|
|
|
Inlet
|
Outlet
|
Normal Type
|
Bellows Type
|
L
|
L1
|
X
|
(VA500)H≈
|
|
11/2G3
|
150
|
150
|
1.96
|
1.58
|
121
|
124
|
32
|
536
|
|
11/2G3
|
300
|
150
|
1.96
|
1.58
|
121
|
124
|
32
|
536
|
|
11/2G3
|
300
|
150
|
1.96
|
1.58
|
152
|
124
|
35
|
536
|
|
11/2G3
|
600
|
150
|
1.96
|
1.58
|
152
|
124
|
35
|
536
|
Throat Dia.H Specification&Dimension
|
d₀=28.3mm
629mm²
|
Flange Rating(Lb)
|
38°C Max. Back Press(Mpa)
|
Dimension(mm)
|
|
|
Inlet
|
Outlet
|
Normal Type
|
Bellows Type
|
L
|
L1
|
X
|
(VA500)H≈
|
|
11/2H3
|
150
|
150
|
1.96
|
1.58
|
124
|
130
|
38
|
542
|
|
11/2H3
|
300
|
150
|
1.96
|
1.58
|
124
|
130
|
38
|
542
|
|
2H3
|
300
|
150
|
1.96
|
1.58
|
124
|
130
|
43
|
666
|
|
2H3
|
600
|
150
|
1.96
|
1.58
|
162
|
154
|
56
|
691
|
Throat Dia.J Specification&Dimension
|
d₀=36mm
1018mm²
|
Flange Rating(Lb)
|
38°C Max. Back Press(Mpa)
|
Dimension(mm)
|
|
|
Inlet
|
Outlet
|
Normal Type
|
Bellows Type
|
L
|
L1
|
X
|
(VA500)H≈
|
|
2J3
|
150
|
150
|
1.96
|
1.58
|
124
|
137
|
49
|
673
|
|
2J3
|
300
|
150
|
1.96
|
1.58
|
124
|
137
|
49
|
673
|
|
2J3
|
300
|
150
|
1.96
|
1.58
|
181
|
184
|
49
|
786
|
|
2J3
|
600
|
150
|
1.96
|
1.58
|
181
|
184
|
49
|
786
|
Throat Dia.K Specification&Dimension
|
d₀=43mm
1452mm²
|
Flange Rating(Lb)
|
38°C Max. Back Press(Mpa)
|
Dimension(mm)
|
|
|
Inlet
|
Outlet
|
Normal Type
|
Bellows Type
|
L
|
L1
|
X
|
(VA500)H≈
|
|
3K4
|
150
|
150
|
1.96
|
1.03
|
162
|
156
|
49
|
758
|
|
3K4
|
300
|
150
|
1.96
|
1.03
|
162
|
156
|
49
|
758
|
|
3K4
|
300
|
150
|
1.96
|
1.03
|
162
|
156
|
49
|
758
|
|
3K4
|
600
|
150
|
1.96
|
1.38
|
181
|
184
|
49
|
786
|
Throat Dia.L Specification&Dimension
|
d₀=53.5mm
2248mm²
|
Flange Rating(Lb)
|
38°C Max. Back Press(Mpa)
|
Dimension(mm)
|
|
|
Inlet
|
Outlet
|
Normal Type
|
Bellows Type
|
L
|
L1
|
X
|
(VA500)H≈
|
|
3L4
|
150
|
150
|
1.96
|
0.69
|
165
|
156
|
49
|
758
|
|
3L4
|
300
|
150
|
1.96
|
0.69
|
165
|
156
|
49
|
758
|
|
4L6
|
300
|
150
|
1.96
|
1.17
|
181
|
179
|
49
|
853
|
|
4L6
|
600
|
150
|
1.96
|
1.17
|
203
|
179
|
57
|
853
|
Throat Dia.M Specification&Dimension
|
d₀=60.3mm
2856mm²
|
Set Press Pk(MPa)
|
38°C Max. Back Press(Mpa)
|
Dimension(mm)
|
|
|
Inlet
|
Outlet
|
Normal Type
|
Bellows Type
|
L
|
L1
|
X
|
(VA500)H≈
|
|
4M6
|
150
|
150
|
1.96
|
0.55
|
184
|
178
|
48
|
852
|
|
4M6
|
300
|
150
|
1.96
|
0.55
|
184
|
178
|
48
|
852
|
|
4M6
|
300
|
150
|
1.96
|
1.10
|
184
|
178
|
48
|
852
|
|
4M6
|
600
|
150
|
1.96
|
1.10
|
203
|
178
|
56
|
852
|
Throat Dia.N Specification&Dimension
|
d₀=66mm
3421mm²
|
Set Press Pk(MPa)
|
38°C Max. Back Press(Mpa)
|
Dimension(mm)
|
|
|
Inlet
|
Outlet
|
Normal Type
|
Bellows Type
|
L
|
L1
|
X
|
(VA500)H≈
|
|
4N6
|
150
|
150
|
1.96
|
0.55
|
210
|
197
|
48
|
871
|
|
4N6
|
300
|
150
|
1.96
|
0.55
|
210
|
197
|
48
|
871
|
|
4N6
|
300
|
150
|
1.96
|
1.10
|
210
|
197
|
48
|
871
|
|
4N6
|
600
|
150
|
1.96
|
1.10
|
222
|
197
|
72
|
871
|
Throat Dia.P Specification&Dimension
|
d₀=80mm
5027mm²
|
Set Press Pk(MPa)
|
38°C Max. Back Press(Mpa)
|
Dimension(mm)
|
|
|
Inlet
|
Outlet
|
Normal Type
|
Bellows Type
|
L
|
L1
|
X
|
(VA500)H≈
|
|
4P6
|
150
|
150
|
1.96
|
0.55
|
229
|
181
|
48
|
855
|
|
4P6
|
300
|
150
|
1.96
|
0.55
|
229
|
181
|
48
|
855
|
|
4P6
|
300
|
150
|
1.96
|
1.03
|
254
|
225
|
62
|
1079
|
|
4P6
|
600
|
150
|
1.96
|
1.03
|
254
|
225
|
62
|
1079
|
Throat Dia.Q Specification&Dimension
|
d₀=105.5mm
8742mm²
|
Set Press Pk(MPa)
|
38°C Max. Back Press(Mpa)
|
Dimension(mm)
|
|
|
Inlet
|
Outlet
|
Normal Type
|
Bellows Type
|
L
|
L1
|
X
|
(VA500)H≈
|
|
6Q8
|
150
|
150
|
0.79
|
0.48
|
241
|
240
|
68
|
855
|
|
6Q8
|
300
|
150
|
0.79
|
0.48
|
241
|
240
|
68
|
1120
|
|
6Q8
|
300
|
150
|
0.79
|
0.79
|
241
|
240
|
68
|
1120
|
|
6Q8
|
600
|
150
|
0.79
|
0.79
|
241
|
240
|
68
|
1120
|
Throat Dia.R Specification&Dimension
|
d₀=126mm
12568mm²
|
Flange Rating(Lb)
|
38°C Max. Back Press(Mpa)
|
Dimension(mm)
|
|
|
Inlet
|
Outlet
|
Normal Type
|
Bellows Type
|
L
|
L1
|
X
|
(VA500)H≈
|
|
6R8
|
150
|
150
|
0.41
|
0.41
|
241
|
240
|
68
|
1120
|
|
6R8
|
300
|
150
|
0.41
|
0.41
|
241
|
240
|
68
|
1120
|
|
6R10
|
300
|
150
|
0.69
|
0.69
|
267
|
240
|
68
|
1426
|
|
6R10
|
600
|
150
|
0.69
|
0.69
|
267
|
240
|
68
|
1426
|
Throat Dia.T Specification&Dimension
|
d₀=161.5mm
20485mm²
|
Flange Rating(Lb)
|
38°C Max. Back Press(Mpa)
|
Dimension(mm)
|
|
|
Inlet
|
Outlet
|
Normal Type
|
Bellows Type
|
L
|
L1
|
X
|
(VA500)H≈
|
|
8T10
|
150
|
150
|
0.20
|
0.20
|
279
|
276
|
62
|
1462
|
|
8T10
|
300
|
150
|
0.20
|
0.20
|
279
|
276
|
62
|
1462
|
|
8T10
|
300
|
150
|
0.41
|
0.41
|
279
|
276
|
62
|
1462
|
|
8T10
|
600
|
150
|
0.69
|
0.69
|
279
|
276
|
62
|
1462
|
